LT01-4G

Product No.:202212511116

  • Details
LT01 is a 4G compact GPS Tracker for vehicles, it is small in size and with internal GPS/GSM antenna. It is designed for motorcycles, cars, vehicles and scooters, the device itself supports 9-100 volts, and it has one digital output for power off relay connecting and one digital input for ignition detect.

_01_02_03

Physical

Dimension

88mm*45mm*14mmL*W*H

Weight

47±5g

Cellular

Lte module

Fibcom L610

Frequency

Working frequency:

LTE FDD: Band 1/3/5/8

LTE TDD: Band 34/38/39/40/41

GSM: 900/1800MHz

LCC 31x28x2.4mm

Operating Temperature: -40~+85

Operating Voltage: 3.3V~4.3V typical 3.8V

GPS

Channels: 50

Sensitivity: -147dBm

Position accuracy:5-10m

Accuracy: 5m CEP

Cold start: <27s

Hot start: <1s

Power

Input voltage

9-100V

Battery

NI-MH AAA 3.6V/110mA, 2 hours working time based on 2-3 minutes upload

Power consumption

Average Current: <30mA (DC 12V)

Maximum current: <10mA (DC 12V)

Interface

Digital input(1)

Ignition detect

Digital output(1)

Relay

GSM antenna

Internal High Gain

GPS antenna

Internal High Gain

SIM

Microsim

Indicator

2 status LEDs, Green: GPS,  Red: 4G

Memory

3000 pcs

Environmental Parameter

Working Temperature

-20 ~ +70

Humidity

5% ~ 95% (no fog)

Ingress Protection Rating

IP65
